Motor
750W, grease packed ball bearing, air-cooled, 110V/60Hz, 220V/50Hz, Single phase
Controls
Spar Mixer controls are side-mounted to give easy access in cramped kitchen environments.
Attachment Hub
10 Attachment Hub can use Pasta Kit, Meat Mincer and Vegetable Prep Attachment.
Transmission
The unique design yields high-torque mixing power while avoiding the high cost encountered repairing direct-drive transmission components.
Bowls and Agitators
Standard equipment includes a 5Litres high quality stainless steel bowl, dough hook, flat beater, and whip. A sturdy hand lever on the body column raises and lowers the bowl as well as locking in place at the top and bottom positions.
Size (L x W x H)
345mm x 389mm x 434mm
Motor
1/3 H.P (250W) AC Motor, grease packed ball bearing, air-cooled, 110V/60Hz, 220V/50Hz, Single phase
Controls
Spar Mixer controls are front-mounted to give easy access in cramped kitchen environments. The following controls are standard on all Spar Mixers: separate start and emergency stop buttons so operators can shut down the mixer immediately in an emergency situation, a 15-minute timer which shuts off the machine after set time has elapsed, and thermal overload protection
Cord and Plug
Single phase are hard wired
Transmission
Heat-treated, hardened alloy, precision milled gears operate with planetary action. Gears are packed in a long-lasting, high pressure grease. This unique design yields high-torque mixing power while avoiding the high cost encountered repairing direct-drive transmission components
Bowls and Agitators
Standard equipment includes a 8 Qt. (7.6Litres) high quality stainless steel bowl, dough hook, flat beater, and whip. A sturdy hand lever on the body column raises and lowers the bowl as well as locking in place at the top and bottom positions.
Size (L x W x H)
346mm x 442mm x 579mm
Motor
1/2 h.p., (370W) grease packed ball bearing, air-cooled, 230V/50Hz/1Ph
Controls
Front-Mounted Control Panel gives easy access in cramped kitchen environments.
Equipped with Emergency Stop Button, Start Button and Mechanical Timer are as standard. Digital Timer Panel is optional.
Cord and Plug
6 ft. flexible three wire cord and ground prong
Transmission
Heat-treated, hardened alloy, precision milled gears operate with planetary action. Gears are packed in a long-lasting, high pressure grease. Planetary gears are driven by direct linkage to the motor drive shaft. This design yields high-torque mixing power.
Bowls and Agitators
Standard equipment includes a 20Qt. (19Litres) high quality stainless steel bowl, dough hook, flat beater, and whip. A sturdy hand lever on the body column raises and lowers the bowl as well as locking in place at the top and bottom positions.
Size (L x W x H)
513mm x 523mm x 874mm
Motor
1 h.p. (750W), grease packed ball bearing, air-cooled, 230V/50Hz/1Ph, 220V/380V/50Hz/3Ph. Powerful 1.5HP Heavy Duty Motor for Pizza Dough is available.
Controls
Front-Mounted Control Panel gives easy access in cramped kitchen environments. Equipped with Emergency Stop Button, Start Button and Mechanical Timer are as standard. Digital Timer Panel is optional.
Cord and Plug
6 ft. flexible three wire cord and ground prong.
Transmission
Heat-treated, hardened alloy, precision milled gears operate with planetary action. Gears are packed in a long-lasting, high pressure grease. Planetary gears are driven by an oversized cog-wheel, which is in turn driven by a cogged belt powered by the motor drive shaft. Cogged belt is a long-lasting, rugged fibre/rubber composite. This unique design yields high-torque mixing power while avoiding the high cost encountered repairing direct-drive transmission components.
Bowls and Agitators
Standard equipment includes a 30Qt. (30L) high quality stainless steel bowl, dough hook, flat beater, and whip. A sturdy hand lever on the body column raises and lowers the bowl as well as locking in place at the top and bottom positions.
Size (L x W x H)
576mm x 668mm x 1,172mm
Motor
3 h.p. (2,250W), grease packed ball bearing, air-cooled, 230V/50Hz/1Ph, 220V/380V/3Ph
Controls
Front-Mounted Control Panel gives easy access in cramped kitchen environments.
Equipped with Emergency Stop Button, Start Button and Mechanical Timer are as standard. Digital Timer Panel is optiona
Cord and Plug
6 ft. flexible three wire cord and ground prong.
Transmission
Heat-treated, hardened alloy, precision milled gears operate with planetary action. Gears are packed in a long-lasting, high pressure grease. Planetary gears are driven by an oversized cog-wheel, which is in turn driven by a cogged belt powered by the motor drive shaft. Cogged belt is a long-lasting, rugged fibre/rubber composite. This unique design yields high-torque mixing power while avoiding the high cost encountered repairing direct-drive transmission components.
Bowls and Agitators
Standard equipment includes a 60Qt. (60L) high quality stainless steel bowl, dough hook, flat beater, and whip. A sturdy hand lever on the body column raises and lowers the bowl as well as locking in place at the top and bottom positions.
Size (L x W x H)
638mm x 778mm x 1,316mm
